YQ15R-D-S 15A Residential Grade Self-Grounding Decorator Receptacle

Short Description:

Residential Grade

Push-In and Side Wired

Duplex Receptacle

Self-Grounding

15A/125V, 5-15R

Send email to us

Product Detail

Product Tags

Features

- Made of polycarbonate

- Push in #14 AWG Cu solid wire for 15A branch circuit only

- Side wire terminals accept #12 or #14 AWG solid copper or

stranded wire

- Shallow design for maximum wiring room

- All devices fit standard wall boxes and are suitable for ganging

- Easy-access green hex head ground screw

- Captive mounting screws

- Washer-type break-off plaster ear for best flush alignment

- Large head combination screws for fast wiring

- Two years warranty

Details

Part Number	YQ15R-D	YQ15R-D-S
Receptacle Amp	15 Amp	15 Amp
Voltage	125VAC	125VAC
Tamper Resistant	—	—
Self-Grounding	—	√
Side Wired	√	√
Back Wired	—	—
Push In Wired	√	√
Color	White,Ivory, Light almond, Gray, Black, Brown
Material	Polycarbonate	Polycarbonate
NEMA	5-15R	5-15R
Certification	UL/CUL Listed	UL/CUL Listed
Environmental	Flammability UL94, V2 Rating	Flammability UL94, V2 Rating
Operating Temperature	-40°C (without impact) to 75°C	-40°C (without impact) to 75°C
Warranty	2 years	2 years

Advantage

- Set up in 2003, with almost 20 years experience in USA Wiring Devices & Lighting Controls, we are capable of developing new items in a short time.
- Work as a partner with World & USA TOP 500 Companies and offer our customers complete product lines by both OEM and ODM .
- Implement PPAP System including MCP, PFMEA, Flow Diagram to well control the product quality.
- Meet both 3rd party and customers’ Factory Audit including THD, Wal-mart, Costco, etc.
- Highly automated production lines which contribute cost saving and assure better lead time.
- Advanced capacity which offers fourty eight 40HQ per month is leading the industry in China.
- UL approved lab offers expert testing and covers all concerns.
- All products UL/ETL approved.
