TWR20-SI 20A Standard Duplex Industrial Grade Self-Grounding Tamper & Weather Resistant Receptacle

Short Description:

Industrial Grade

Back and Side Wired, 2 Pole, 3 Wire

Grounding, Self-Grounding

Standard Duplex Receptacle,

Tamper & Weather Resistant,

20A/125V, 5-20R

Send email to us

Product Detail

Product Tags

Features

- US utility patented for TR mechanism

- Impact resistant thermoplastic construction

- Built-In protective shutter mechanism designed to prevent the

insertion of foreign objects into the receptacle contact openings

- Weather-Resistant Receptacles be installed in wet or damp

locations such as porches, decks, and other outdoor locations

where challenging conditions can cause premature failure due to

cracked covers and corrosion

- All devices fit standard wall boxes and are suitable for ganging

- Side wire terminals accept #12 or #14 AWG solid copper or

stranded wire

- Two years warranty

Technical Parameters

Part Number	TWR20-SI
Amperage	20 A
Voltage	125 VAC
Grade	Hospital Grade
Pole	2
Type	Decorstor Receptacle
Finish	Glossy
Termination	Side Wired & Back Wired
Face Material	Polycarbonate
Strap Material	Steel
NEMA	5-20 R
Certification	UL/CUL Listed
Color	White,Ivory, Light almond, Gray, Black, Brown
Environmental	Flammability UL94, V2 Rating
Operating Temperature	-40°C (without impact) to 75°C
Warranty	2 years

Advantage

- Set up in 2003, with almost 20 years experience in USA Wiring Devices & Lighting Controls, we are capable of developing new items in a short time.
- Work as a partner with World & USA TOP 500 Companies and offer our customers complete product lines by both OEM and ODM.
- Implement PPAP System including MCP, PFMEA, Flow Diagram to well control the product quality.
- Meet both 3rd party and customers’ Factory Audit including THD, Wal-mart, Costco, GE, Schneider, etc.
- Highly automated production lines which contribute cost saving and assure better lead time.
- Advanced capacity which offers fourty eight 40HQ per month is leading the industry in China.
- All products UL/ETL approved.
