TR15-SC Commercial Grade Tamper-Resistant Duplex Receptacle

Short Description:

Commercial Grade

Back and Side Wired

Duplex Receptacle, Tamper-Resistant,

15A/125V, 5-15R

Self-Grounding

Color: White / Ivory

Send email to us

Product Detail

Product Tags

Features

- US utility patented for TR mechanism

- Impact-resistant thermoplastic cover and body

- All terminal and mounting screws combination head

- Push-in and side-wiring options

- Easy-to-read “TR” markings onto face

- Tamper resistant version features dual mechanical shutter

system to help prevent insertion of foreign objects

- Smooth face does not collect dirt

- All devices fit standard wall boxes and are suitable for ganging

- Side wire terminals accept #12 or #14 AWG solid copper or

stranded wire

- Two years warranty

Details

Part Number	TR15-SC	TR20-SC
Receptacle Amp	15 Amp	20 Amp
Voltage	125VAC	125VAC
Tamper Resistant	√	√
Self-Grounding	√	√
Side Wired	√	√
Back Wired	√	√
Push In Wired	—	—
Color	White,Ivory
Material	Polycarbonate	Polycarbonate
NEMA	5-15R	5-20R
Certification	UL/CUL Listed	UL/CUL Listed
Environmental	Flammability UL94, V2 Rating	Flammability UL94, V2 Rating
Operating Temperature	-40°C (without impact) to 75°C	-40°C (without impact) to 75°C
Warranty	2 years	2 years

Advantage

- Set up in 2003, with almost 20 years experience in USA Wiring Devices & Lighting Controls, we are capable of developing new items in a short time.
- Work as a partner with World & USA TOP 500 Companies and offer our customers complete product lines by both OEM and ODM .
- Implement PPAP System including MCP, PFMEA, Flow Diagram to well control the product quality.
- Meet both 3rd party and customers’ Factory Audit including THD, Wal-mart, Costco, GE, Schneider, etc.
- Highly automated production lines which contribute cost saving and assure better lead time.
- Advanced capacity which offers fourty eight 40HQ per month is leading the industry in China.
- UL approved lab offers expert testing and covers all concerns.
- All products UL/ETL approved.
