MPC-50HD High Bay PIR Occupancy With 0-10V Dimming

Short Description:

High Bay PIR Occupancy

With 0-10V Dimming

360°, MPC-50HD-L2: 1200 sq.ft.

MPC-50HD-L1: 2800 sq.ft.

Tungsten: 800W@120VAC

Resistive: 10A@120/277VAC

Ballast: 800VA@120VAC

1385VA@277VAC

Motor: 1/4HP@120VAC

Two Lens L1: 15-50ft, L2: 8-12ft

Send email to us

Product Detail

Product Tags

Feature

- -PIR motion

Using passive infrared technology, PIR motion sensors automatically turn on/off lights.

It features a bright LED indicator when the sensor senses motion.

–360 interchangeable lens

Two interchangeable Fresnel lenses for perfect detection based on application needs.

Up to 2800 sq. ft coverage, 360 degree field view.This allows the sensor to cover any ceiling height from 8 feet to 50 feet.

– Versatile Compatibility
Compatible with LED, incandescent, CFL lighting.

– Adjustable Settings
Customize to your preferences with a time delay from 15 sec to 30 mins.

Easy adjustable sensitivity control via DIP switch. Adjustable sensitivity 50%-100%.

–Easy Installation

Only requires a 1/2 inch knockout cutting material costs and installation time.

Advantage

– 10+ years experience in design and manufacturing.
–A wide selection of products.
–ALL of our goods have got certificates such as cULus and cETLus etc.
–We have sold our products to GE, THD, LOWE’S, Wal-Mart, etc.
– The capabilities of our team and equipment allow us to design, develop, and do more than just OEM and ODM.
–The production area is about 20000square meter (WENZHOU).

Deatils

Part Number	MPC-50HD
Input Voltage	120-277V AC
Incandescent	800 W@120V AC
Ballast	800VA @120V AC, 1385VA@277V AC
Resistive	10A
Motor	1/4HP @120V AC
Usage	Indoor Use Only, In-Wall Use Only
Operating Temperature	32°F to 131°F(0°C to 55°C)
Relative Humidity	20-90%, non-condensing
Material	ABS
Adjustment Time Delay	15 Sec. to 30 Mins
Batteries Included?	No
Batteries Required?	No

CAT. NO.	DESCRIPTION
MPC-50H	High Bay 360° PIR Line Voltage Occupancy Sensor ( Power Pack not Required)
MPC-50V	360° PIR Line Voltage Occupancy Sensor( Power Pack not Required)
MPC-50L	360° PIR Low Voltage Occupancy Sensor, Requires MPP-24 Power Pack
MDC-50V	360° Dual-Technology PIR/Ultrasonic Line Voltage Occupancy Sensor ( Power Pack not Required)
MDC-50L	360° Dual-Technology PIR/Ultrasonic Low Voltage Occupancy Sensor,Requires MPP-24 Power Pack
